Manual Screen Printer Machine,Curved Press Kit,for Cylindrical Objects,6.7in Max Diameter,Professional Printing,for Pens Tumblers Bottles Cups

➤➤➤ Product DescriptionThis curved screen printer is a manual screen printer with a diameter of up to 170mm, a 160mm vertical adjustment range, and three sets of rollers. It is suitable for cylindrical/conical products and is widely used in clothing stores, manufacturing plants, machinery repair shops, retail stores, printing companies, advertising agencies, and more.➤ Instructions:1. Install the screen frame and adjust it to the appropriate height. Adjust the handle position according to your usage.2. Install the scraper and secure it 1-2 cm away from the design.3. Adjust the position of the print frame and roller bearings. Place the printed material on the roller, leaving a gap between the material and the screen frame. Ensure that the printed material is aligned with the squeegee.4. Adjust the screen frame position and pour ink.➤ Specifications:- Name: Cylinder Screen Printing Press- Material: Steel- Color: Blue- Structure: Front-to-rear push-pull- Maximum Image Size: 200 x 250 mm / 7.87 x 9.84 in- Applicable Screen: Outer Diameter 280 x 450 mm / 11.02 x 17.72 in- Maximum Screen Thickness: 40 mm / 1.57 in- Vertical Adjustment Range: 160 mm / 6.30 in- Maximum Cylinder/Cone Diameter: 170 mm / 6.69 in- Package Dimensions: 62 x 35 x 36 cm / 24.41 x 13.78 x 14.17 in- Package Weight: 14 kg / 30.86 lbs➤ Packing List:1 x Curved Screen Printer1 x Squeegee3 x Rollers➤ Customer Service:If you have any questions about this product, please contact me and I will respond within 24 hours!

• ➤【Manual Curved Screen Printer】：HaiZethonic Maximum image area: 200 x 250 mm; Applicable screen: Outer diameter 280 x 450 mm; Maximum screen thickness: 40 mm; Vertical adjustment range: 160 mm; Maximum cylindrical/conical diameter: 170 mm
• ➤【Three Sets of Rollers】： round screen printer uses three sets of rollers to position the substrate: a 19 mm diameter metal roller, a 25 mm diameter nylon roller, and a 50 mm diameter plastic roller. These rollers can be replaced as needed, and both the main and auxiliary frames can accommodate these three types of rollers.
• ➤【Adjustable Height】： curved screen printer utilizes a rear main frame with height adjustment. The rear main crossbeam is adjusted up and down by adjusting the column screws according to the substrate height. The adjustment range is 160 mm, allowing printing on cylindrical and conical products with diameters less than 170 mm.
• ➤【Forward, Backward, and Left/Right Movement】： curved screen printer's aluminum bar base rails allow for 300mm of forward and backward movement. The bearing brackets are mounted directly on the aluminum bar mounting holes, allowing for up to 120mm of left and right movement, depending on substrate width.
• ➤【Wide Application】：cylindrical screen printer is suitable for printing on cylindrical/conical surfaces, including glass bottles (such as wine bottles, medicine bottles, and cosmetic bottles), metal containers, various types of cups (mugs, beer glasses, and wine glasses), and small cylindrical products such as glass tubes and baseball bats.
